KY-150 hydraulic exploration drilling rig for metal mine
Keywords:
Categories：
产品描述
- 产品描述
-
- Commodity name: KY-150 hydraulic exploration drilling rig for metal mine
1.Features of KY-150 hydraulic exploration drilling rig for metal mine
KY-150 hydraulic exploration drilling rig for metal mine is easy to disassemble and convenient to transport. The drilling rig has flexible arrangement, and the drilling pipe can be dismantled mechanically, which can reduce labor cost and improve work efficiency. Also the rig has infiniTely variable speeds.
KY-150 hydraulic exploration drilling rig for metal mine has the function of linkage. It is simple and safe to control the rig through the operation platform. The spindle of the gyration adopts the through hole structure. The length of the drill pipe is not restricted by the drilling rig, and it can also be applied to diamond wire-line coring drilling.
KY-150 hydraulic exploration drilling rig for metal mine uses full hydraulic operation to make the structure more reasonable to make the function more complete. It uses variable motor which has wide speed regulating range. This drilling rig applies to high speed drilling of alloy steel stone and hard alloy drilling at low speed, and it is suitable for any inclination drilling in the tunnel or surface drilling.
2.Components of KY-150 hydraulic exploration drilling rig for metal mine
The KY-150 hydraulic exploration drilling rig for metal mine adopts the structure of full hydraulic power head, and consists of three parts: main engine, pumping station and operating flatform.
3.Specifications of KY-150 hydraulic exploration drilling rig for metal mine
KY-150 hydraulic exploration drilling rig for metal mine Borehole diameter
36.5mm/46.5mm
Drilling depth
150m (φ33 steel drill pipe)
120m (φ43 steel drill pipe)
150m (φ43 aluminum alloy drill pipe)
Borehole angle
0°-360°
Spindle speed
400-1400 r/min
Spindle output torque
87-300 n.m
Rated pull force
30 kn
Rated pull speed
> 0.3 m/s
Oil supply mode
double gear pump
Hydraulic oil mode
antiwear hydraulic oil YB-N46/YB-N32 (winter)
Motor model
manual variable motor A6V55MA
Motor specifications
Y180M-4/18.5 kw
Equipment weight
main engine 166kg
pillar 40kg
operation platform 86kg
pumping station 210kg
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
