    • Commodity name: KHYD110 electric rock drilling rig

    1.Brief introductions of KHYD110 electric rock drilling rig

    (1)The electric rock drilling rig can be fitted with drill stand, and can be drilled horizontally or upward in any direction.

    (2)In order to prolong the service life of the drill bit and improve the working conditions of the operator, wet drilled water can be used to discharge the powder and screw blade drills can also be used for dry draining.

    (3)In the operation of electric motor rock drilling rig, we only need to operate the handwheel, and the electric motor rock drilling rig can advance itself and return quickly.

    2.Specifications of KHYD110 electric rock drilling rig

    Model

    Unit

    KHYD110

    Rated output power of motor

    kw

    5.5

    Rated voltage of motor

    v

    380/660

    Rated frequency of motor

    hz

    50

    Rated current of motor

    a

    11.6

    Motor speed

    r/min

    1440

    Motor phase number



    three phase communication

    Rated working mode



    continuity

    Drilling speed

    mm/min

    280

    Speed of return

    m/min



    Borehole diameter

    mm

    42-80(rock)

    Hardness range

    protodikonov`s scale of hardness

    f<10

    Maximum drilling depth

    m

    20(rock)

    Weight of drilling rig (excluding runways, drill pipes, drills)

    kg

    110

    Dimension (length * width * height)

    mm

    950*460*430

    Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
