YN27P internal combustion crushing pick

YN27P internal combustion crushing pick

Product description

1.Purpose of YN27P internal combustion crushing pick

YN27P internal combustion impact breaker has the functions of splitting, crushing and shoveling for reinforced concrete, cement pavement, asphalt pavement, frozen soil layer, ice layer, soft ore, soft rock layer, road construction and other occasions. It is widely used in construction and mining. Road construction, quarrying, fire rescue and rescue, national defense engineering, highway maintenance, various demolition, piling, fixed tents, grounding rods and detection of geological pollution and railway repair work.

2. Parameters of YN27P internal combustion crushing pick

Host weight: 25kg

Contour size: 730*315*229mm

Engine type: Single cylinder air-cooled two-stroke gasoline engine

Carburetor type: No float

Ignition method: Thermistor contactless system

Engine piston diameter: 58 mm

Engine piston stroke: 70 mm

Engine capacity:185 cm³

Shank size tail: Hexagon 22*108mm

Fuel tank capacity:≥1.14L

Gasoline and lubricating oil mixing ratio (by volume): 12:1

Spark plug electrode gap: 0.7 ~ 1mm

Fuel consumption rate: ≤1.2L/h

Impact energy: ≥45J

Shandong Master Machinery Group specializes in supplying internal combustion rock drills. The main models are YN27A, YN27P and YN27C.

Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
