D3 pneumatic tamping machine
D3 pneumatic tamping machine
1.Uses for D3 Pneumatic Tamping Machine
D3 pneumatic tamping machine is used as the power for compressed air. It is suitable for the tamping of casting sand type, and can also be used for concrete and brick work. The D3 type is extremely small and is used in applications where the working space is narrow.
2. Parameters of D3 Pneumatic Tamping Machine
|
D3 Pneumatic tamping machine |
||
|---|---|---|
|
Weight |
kg |
2.5 |
|
Working pressure |
mpa |
0.63 |
|
Air consumption |
m³/min |
0.25 |
|
Number of impacts |
times/min |
900 |
|
Piston diameter |
mm |
17 |
|
Structural stroke |
mm |
92 |
|
Hammer diameter |
mm |
32 |
|
Air pipe inner diameter |
mm |
13 |
|
Full length |
mm |
430 |
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
