TRZQ series ground drill
TRZQ series ground drill
一、Introduction to TRZQ series ground drills
1. The TRZQ series ground auger is composed of a small gasoline engine, gear box and designed drilling tools. It is suitable for drilling holes in the ground, frozen soil and ice layer, and is widely used in afforestation, planting fruit forests, fences and fertilizing fruit trees in autumn.
2. The drill bit is made of manganese steel to make it harder. It can work on hard soil, super hard soil, clay and frozen soil.
3. The ground drill can be equipped with a variety of drill bits to meet the needs of users.
4.TRZQ series ground drill parameters
|
model |
49.9cc Two stroke ground drill |
52cc Two stroke ground drill |
63cc Two stroke ground drill |
71cc Two stroke ground drill |
173cc Four stroke ground drill |
212cc Four stroke ground drill |
|---|---|---|---|---|---|---|
|
Engine form |
Air-cooled single cylinder two-stroke. |
Air-cooled single cylinder two-stroke. |
Air-cooled single cylinder two-stroke. |
Air-cooled single cylinder two-stroke. |
Four stroke |
Four stroke |
|
Engine displacement |
49.9cc |
52cc |
63cc |
71cc |
173CC |
212cc |
|
Engine power |
1.9kw/7000r/min |
1.9kw/7500r/min |
2.2kw/7500r/min |
4.8HP/3.2KW |
7HP/4700rpm |
≤5.9KW |
|
Transmission mode |
Gearshift drive |
Gearbox variable transmission |
Gearbox variable transmission |
Gearbox variable transmission |
Gearbox variable transmission |
Gearbox variable transmission |
|
Start mode |
Hand pull recoil start |
Hand pull recoil start |
Hand pull recoil start |
Hang pull back rope start |
Hand pull recoil start |
Hand pull recoil start |
|
Fuel ratio |
Gasoline and two stroke oil25：1 |
Gasoline and two stroke oil25：1 |
Gasoline and two stroke oil25：1 |
Gasoline and two stroke oil25：1 |
Pure gasoline |
Pure gasoline |
|
Fuel tank volume |
1200ml |
1200ml |
1200ml |
1200ml |
1.54L |
3.6L |
|
Net weight |
10.5kg |
10kg |
10kg |
9.5kg |
25/30kg |
28/33kg |
|
Bit diameter. |
40/60/80/100/150 /200/250/300mm |
40/60/80/100/150/200 /250/300/350/400/500mm |
||||
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
