YSQ hydraulic crushing pliers

YSQ hydraulic crushing pliers

没有此类产品
Product description

1. Brief introduction of YSQ crushing pliers

The hydraulic crushing pliers is a static hydraulic breaking equipment produced by Shandong Master Machinery Group. The hydraulic breaker is mainly composed of a hydraulic pump station, a hydraulic clamp body, and a high-pressure tubing. The hydraulic pumping station pumps ultra-high pressure hydraulic oil, and the clamp is pushed through the cylinder to break the concrete, which can meet the needs of partial removal, retaining steel bars and various demolition needs. Hydraulic crushing pliers have been widely used in static crushing, floor slabs, concrete beams, concrete walls, concrete pillar overhangs, staircase removal and other projects.

2. Features of YSQ hydraulic crushing pliers

(1) Compared with traditional working methods, hydraulic crushing tongs have the characteristics of safety and environmental protection, simple structure, convenient operation, high efficiency and low cost.

(2) Adopt modular design, easy to assemble and disassemble.

(3) Small size, light weight, convenient to move and easy to maintain, and low maintenance cost.

(4) The hydraulic pump station is easy to start, flexible in operation, strong in power and reliable in performance.

(5) The hydraulic clamp body is made of high-strength steel and undergoes strict heat treatment process, with reasonable structure and reliable quality

3. Parameters of YSQ hydraulic crushing pliers

Model

YSQ-200

YSQ-250

YSQ-320

YSQ-350

YSQ-400

YSQ-500

Opening diameter (mm)

200 250 320 350 400 500

Demolition force (T)

40 50 55 60 70 80

Weight (kg)

60 86 138 142 150 200

Pressure (Mpa)

80 80 80 80 80 80

Pump station

Power (kw)

      4

Voltage (V)

380/220
