XWC Series Wheeled Rotary Pile Drilling Rig
Keywords:
Categories：
产品描述
- 产品描述
-
- Commodity name: XWC Series Wheeled Rotary Pile Drilling Rig
1. Introduction of XWC series wheeled rotary pile drilling rig
XWC series wheeled rotary pile drilling rig is a kind of rotary pile drilling rig, which is suitable for building construction foundation. It is widely used in the construction of various soil layers, such as sand, clay, silty soil and so on. At the same time, it is widely used in the construction of cast-in-place piles, continuous walls, foundation reinforcement. The small rotary drilling rig has the characteristics of low noise, small vibration, large torque, muti-function, fast drilling speed, flexible in operation, high construction efficiency, various speed regulation, electronic automatic monitoring.These characteristics gradually replace some traditional piling and drilling equipment.
2. Parameters of XWC series wheeled rotary pile drilling rig
Model
XWL-13.5
XWL-15
Work Mode
Cylinder pressurization
Cylinder pressurization
Drilling diameter
mm
500-1500mm
Drilling depth
m
13.5
15
Dimensions
m
7.15*2.42*3.30
7.79*2.42*3.30
Complete machine weight
t
7.6
8.5
Tire model
/
900-20
Engine model
/
4108
6105
Engine power
kw
88
125
Power head torque
kn.m
23000
Power head speed
r/min
30-50
Lift force
kn
≤150
Itinerary
m
≤11-22
wire rope diameter
mm
16
Rotation angle
°
180
walking speed
km/h
50
Climbability
°
25-30
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
