QTZ-3D Electric Portable Soil Sampling Drilling Rig
Keywords:
Categories：
产品描述
- 产品描述
-
- Commodity name: QTZ-3D Electric Portable Soil Sampling Drilling Rig
1. Brief introductions of QTZ-3D electric portable soil sampling drilling rig
QTZ-3D electric portable soil sampling drilling rig is an electric version of the QTZ-3 soil drilling rig (gasoline engine).
The improvement of QTZ-3D electric portable soil sampling drilling rig is mainly engine system. While QTZ-3 soil sampling drilling rig is equipped with gasoline engine, QTZ-3D is powered by electric. The QTZ-3D electric portable soil sampling drilling rig selects pure copper winding two phase electric motor as a power source. The advantage of using the electric engine as the power source is its stability, and it can continuously improve the working efficiency with a certain kind of power operation equipment. It greatly improves the feed speed. In addition, QTZ-3D electric portable soil sampling drilling rig is easy to operate, safe and stable, and can greatly reduce the labor force during the drilling operations.
2. Applications of QTZ-3D electric portable soil sampling drilling rig
（1）geotechnical investigation
（2）environmental soil survey
（3）gricultural soil survey
（4）groundwater survey
（5）coastal geological survey
（6）wetland environmental investigation
（7）tailing pond investigation
（8）archaeological investigation
（9）physical chemistry exploration secondary halo sampling
（10）the description of soil structure
3. Technical parameter s of QTZ-3D electric portable soil sampling drilling rig
Model
QTZ-3D
Voltage
220v
Power
3.6kw
Lighter way
switch mode
Energy dissipation
low power consumption
Impact times
2600min/m
Impact energy
60j-79j
Core depth
15m-20m
Host weight
22kg
4. Configuration list of QTZ-3D electric portable soil sampling drilling rig
Name
Model
Company
Number
Main engine of soil drilling rig
QTZ-3D
set
1
Square buckle impact handle
Φ34
pc
1
drill pipe
Φ34*1000mm
pc
15
head
Φ50/34
pc
1
Coupling
Φ50
pc
1
Split pipe
Φ50
pc
1
Inner edge pipe shoe
Φ50
pc
1
Outer edge pipe shoe
Φ50
pc
1
head
Φ73/34
pc
1
Coupling
Φ73
pc
1
Split pipe
Φ73
pc
1
Inner edge pipe shoe
Φ73
pc
1
Outer edge pipe shoe
Φ73
pc
1
Portable penetration hammer
10KG
pc
1
Hit the head
Φ34
pc
1
Take over on both sides
Φ34
pc
1
Touch probe
Φ34
pc
1
Extractor
Three position arm
pc
1
tool kit
pc
1
Pipe tongs
pc
2
Wrench
pc
1
Soil shovel
pc
1
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product
