KY-250 Hydraulic Exploration Drilling Rig For Metal Mine
Keywords:
Categories：
产品描述
- 产品描述
-
- Commodity name: KY-250 Hydraulic Exploration Drilling Rig For Metal Mine
1. Brief introductions of KY-250 hydraulic exploration drilling rig for metal mine
The KY250 hydraulic exploration drilling rig for metal mine is suitable for drilling at any angle in the tunnel or surface. It is small in size, light in weight, convenient to install and operate with adjustable speed and good linkage performance.
2. Specifications of KY-250 hydraulic exploration drilling rig for metal mine
Model
KY-250
Drilling diameter
Φ36.5mm /Φ46.5mm
Drilling depth
250m（ø33 Steel drill pipe）
200m（ø43 Steel drill pipe）
Borehole angle
0°-360°
Spindle speed
400-1400r/min
Spindle output torque
150-400nm
Rated pulling force
40kn
Rated pulling speed
＞0.3m/s
Oil supply mode
double gear pump
Rated system pressure
16mpa
Oil pump model
CBF-F71/10
Hydraulic oil model
antiwear hydraulic oil YB-N46/YB-N32 (winter)
Motor model
manual variable motor A6V80MA
Motor specification
30kw
Weight
main engine 275kg
pillar 40kg
operating platform 86kg
pumping station 420kg
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
