QZ-2C Gasoline Engine Sampling Drilling Rig
Keywords:
Categories：
产品描述
- 产品描述
-
- Commodity name: QZ-2C Gasoline Engine Sampling Drilling Rig
1. Brief introductions of QZ-2C gasoline engine sampling drilling rig
QZ-2C gasoline engine sampling drilling rig is used for geological industrial and civil buildings, bridges, railway, highway, hydro power industry survey, geophysical exploration, advanced drilling and grouting hole drilling.
QZ-2C gasoline engine sampling drilling rig has the following features: compact structure, small volume, light weight, two gears, easy to move.
2. Technical parameters of QZ-2C gasoline engine sampling drilling rig
Model
QZ-2C
Bottom hole diameter (mm)
32-91
Drilling depth（m）
soil φ91：10-15m
rock φ91：5-10m
rock φ75：10-15m
rock φ60：15-20m
rock φ46：20-30mDrilling pipe diameter (mm)
30
Gasoline engine
horse power(hp）
6(4.5kw)
displacement（cc）
224
Dimension（l*w*h）
600*450*1900
Weight（kg）
95
3. Configuration list of QZ-2C gasoline engine sampling drilling rig
Item
Parameter
Unit
Quantity
Gasoline engine sampling drilling rig
QZ-2C
set
1
Drilling pipe
30*1500
pc
6
Drilling pipe
30*800
pc
14
Pipe joint
38
pc
20
Reducing nipple
58/38
pc
2
Core barrel
58*800
pc
1
Core barrel
58*1500
pc
1
Alloy bit
60
pc
1
Diamond bit
60
pc
1
Reducing nipple
73/38
pc
2
Core barrel
73*800
pc
1
Alloy bit
75
pc
1
Diamond bit
75
pc
1
Three-wing bit
75
pc
1
Safety clamp
pc
1
Water seal
Y 30*50*10
pc
4
Oil seal
30*50*10
pc
1
Pipe wrench
18
pc
2
Monkey wrench
pc
1
Shaft snap ring clamp
pc
1
Hole snap ring clamp
pc
1
Clamp
pc
1
Cross screwdriver
pc
1
Hex wrench
pc
1
Control wheel
pc
1
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
