QZ-2A Three Phase Electric Sampling Drilling Rig
Keywords:
Categories：
产品描述
- 产品描述
-
- Commodity name: QZ-2A Three Phase Electric Sampling Drilling Rig
1. Brief introduction of QZ-2A three phase electric sampling drilling rig
QZ-2A is a three phase electric sampling drilling rig , produced by Shandong Master Machinery Group. It is suitable for industrial and civil buildings, bridges, railways, roads, utilities and other sectors of the geological exploration.
2. Technical parameters of QZ-2A three phase electric sampling drilling rig
Model
QZ-2A
Borehole diameter (mm)
32-91
Drilling depth（m）
soil φ91：10-15m
rock φ91：5-10m
rock φ75：10-15m
rock φ60：15-20m
rock φ46：20-25mDrilling pipe diameter (mm)
28
Rotate speed（r/min）
185-380
Torque（n.m）
80
Power（kw）
3
Dimension（l*w*h）
600*450*1900
Weight（kg）
95
3. Configuration list of QZ-2A three phase electric sampling drilling rig
Item
Parameter
Unit
Quantity
Three phase electric sampling drilling rig
QZ-2A
set
1
Drilling pipe
28*1500
pc
6
Drilling pipe
28*800
pc
8
Drilling joint
35
pc
14
Reducing nipple
45/35
pc
1
Core barrel
45*800
pc
1
Alloy bit
46
pc
1
Reducing nipple
58/35
pc
1
Core barrel
58*800
pc
1
Alloy bit
60
pc
1
Three-wing bit
60
pc
1
Safety clamp
pc
1
Water seal
Y30*50*10
pc
4
Oil seal
17*50*10
pc
2
Control wheel
set
1
Note: The product is continuously improved, and subject to change without notice, please refer to the actual product
