MYT-125/400 Hydraulic Roof Bolter Drilling Rig
Keywords:
Categories：
产品描述
- 产品描述
-
- Commodity name: MYT-125/400 Hydraulic Roof Bolter Drilling Rig
1. Technical Description of MYT-125/400 Hydraulic Roof Bolter Drilling Rig
It is mainly used in various rock roadways, semi-coal rock roadways and coal roadways with roof hardness f0-10 to drill anchor holes in the roof and install anchor rods. The machine has large torque, light weight, low noise and high efficiency. It can drill φ27－φ42 bolt and anchor cable holes, and the hole depth can reach 20 meters. The drilling rig is equipped with a hydraulic pump station, which can also be used in conjunction with the roadheader.
2. MYT-125/400 Hydraulic Roof Bolter Drilling Rig Parameters
Project
Content
Unit
Value
Remarks
Host
Rated pressure
MPa
12.5
Rated torque
N.m
125
Rated speed
r/min
400
Rated flow
L/min
46
Main pump/secondary pump
Propulsion
(first level, second level)
kN
Adjustable
Adjustable with rock hardness
No-load propulsion speed
mm/min
5000
Return speed
mm/min
9000
Rig height
A
B
C
D
Rig height
mm
1100~2200
1200~2500
1300~2800
1500~3400
Advance itinerary
mm
1100
1300
1500
1900
Rinse water pressure
MPa
0.6-1
Drilling diameter
mm
∮27-∮42
Noise
dB(A)
<92
Sound pressure level
<108
Sound power level
Rig Weight
Kg
48±2.5
50±2.5
52±2.5
55±2.5
Pumping station
Rated pressure
MPa
13
Rated flow
L/min
46
Fuel tank effective volume
L
110
Dimensions
mm
1200X450X850
Fuel tank weight
(no oil)
kg
248±5
Motor
Motor model
YBK2-160M-4
Motor rated power
kW
11
Motor rated voltage
V
380/660 or 660/1140
Motor rated current
A
22.6/13.1
Note: The product is constantly improving, and if there is any change without prior notice, please refer to the actual product.
